gebraucht
Reference ID PP-62886 Category Flatbed Die Cutter Manufacturer Iberica Model TR105F Year Built 2004 Color - Impression - Working Hours - Speed - - Max. Size 750 x 1050 mm Min. Size - Condition Good Location Europe Availability Immediately Machine Description 27632 hours Stripping station Max. size: 750 x 1050 mm. Min. size: 350 x 450 mm. Min grammage: 90g/m2 Max. for solid: 1,5 mm. Max. for corrugated: 3 mm. Max. pressure 300 T Max. speed: 9000 ark/h 1 mm. Plates system with micrometric In production
gebraucht
gebraucht
Heidelberg Prägetiegel TP, Maschinennummer T169693+ Heidelberg Prägetiegel TP,T191298, Maschine ist in einem guten Zustand, sofort Verfügbar Bei Interesse informieren wir Sie auch gerne über weitere Maschinen in unserem Haus. Sie sind herzlich willkommen, nach vorheriger Terminabsprache, die Maschine in unserem Haus zu besichtigen.
gebraucht
Stanztiegel TMZ Type L122, BJ 1997, Format 93x126 cm, Stanzkraft 350 to., Geschwindigkeit 1400 U/Std., Schnellspannrahmen, Sicherheitsfußmatten, in einem guten Zustand, sofort Verfügbar
gebraucht
Stanztiegel Gietz MDST, Maschinennummer 11848, Baujahr 1989, in einem guten Zustand, sofort Verfügbar Wir haben noch zwei weitere Gietz Modelle. Bitte fordern Sie ein Angebot an. Bei Interesse informieren wir Sie auch gerne über weitere Maschinen in unserem Haus. Sie sind herzlich willkommen, nach vorheriger Terminabsprache, die Maschine in unserem Haus zu besichtigen.
gebraucht
Reference ID: PP-62429 Manufacturer: Bobst Model: SP 142 CER Year: 1995 Max. Size: 1420 x 1020 mm Condition: Good Location: Europe Availability: Immediately Manufacturer: BOBST Model: SP 142-CER Year of manufacture: 1995 Maximum sheet size: 1,420 × 1,020 mm Minimum sheet size: 700 × 500 mm Maximum rated speed: 8,000 sheets/hour Maximum cutting force: 5.5 MN (550 t) Recorded operating hours: 51,652 h Condition: Good and fully operational Inspection: Available with the machine running, by appointment Equipment and configuration Automatic sheet-fed flatbed die-cutting system Die-cutting and creasing section Stripping section for removal of cutting waste Blanking section for sepa ...
gebraucht
Reference ID PP-62514 Category Flatbed Die Cutter Manufacturer Bobst Model SP 102-BMA Year Built 1987 Color - Impression - Working Hours - Speed - - Max. Size 720 × 1.020 mm Min. Size 350 × 400 mm Condition Good Location Europe Availability Immediately Machine Description Machine type: Automatic hot-foil stamping, embossing and carton converting press Maximum sheet size: 1,020 × 720 mm Minimum sheet size: 400 × 350 mm Maximum hot-foil stamping / embossing area: 1,010 × 680 mm Maximum cutting die full size: 1,040 × 725 mm Maximum die-cutting size with gripper margin: 1,020 × 705 mm Maximum die-cutting size without gripper margin: 1,020 × 720 mm
gebraucht
IMG Klett Cobra Express A 12-165 – Automatic flatbed die cutter Year: 2009 Max. sheet size: 1,200 × 1,650 mm; min.: 450 × 650 mm Max. cutting size: 1,180 × 1,630 mm; max. cutting force: 450 t Mechanical speed: up to 6,000 strokes/h Corrugated board: 1–8 mm; solid board: 1–4.5 mm Cutting-rule height: 23.8 mm Fully automatic machine with quick-change tooling system. Reference: PP-54365 Further information on request.
gebraucht
Bobst / Iberica TR-105 F – Flatbed die cutter Year: 2003 Max. sheet size: 750 × 1,050 mm; min.: 350 × 400 mm Speed: up to 9,000 sheets/h Corrugated board thickness: up to 3 mm Non-stop arrangement with belt. Reference: PP-56295 Further information on request.
gebraucht
Bobst SP 142 CER MATIC – Flatbed die cutter with blanking Year: 1990 Max. sheet size: 1,020 × 1,420 mm; min.: 700 × 500 mm Equipment: Automatic sheet feeder and lateral BOBST Centerline system Die-cutting, creasing, stripping and automatic blanking Automatic non-stop delivery and waste extraction Operator platforms and quick cutting-frame change BOBST factory retrofit with upgraded controls and safety equipment Reference: PP-60850 Further information on request.
gebraucht
Reference ID PP-61911 Category Flatbed Die Cutter Manufacturer Bobst Model SP 102 E II Year Built 2000 Color - Impression - Working Hours 63000 Speed - - Max. Size 720x120 mm Min. Size 350x400 mm Condition Good Location Europe Availability Immediately Machine Description Feed Table, Die-Cutting Section, Stripping Section, Delivery with Non-Stop Rack, Centerline System, BOBST Electronic System, Standard Equipment Die-Cutting: Upper Chase E-001; Lower Cutting Plate E-004 (4 mm); Lower Support Plate with adjustable centering. Stripping: Upper Stripping Frame F-002 with tooling F-021/F-022; Quick Locking Device F-076; Lower Stripping Frame F-008 with tooling F-081. B-007 Standard-height ...
gebraucht
Heidelberg Cylinder SGS Die Cutting machine Age: 1973 Max. Sheet Format: 72 x 104 cm Min. Sheet Format: 40 x 55 cm Stacking height: 115 cm in Feeder, 100 cm in delivery Performance: max. 4000 sheets/hour Power: circa 400 tons Counter: 13,4 mio. 3x Chases Machine in very good condition
gebraucht
Rabolini Imperia „F Gold with Hot Foil stamping Age: 2020 Max. Sheet Format: 120 x 165 cm Punching force: 380 tons Performance: up to 1300 sheets/hour Max. solid cardboard thickness: 1,6 mm Max. Corrugated Cardboard thickness: 7 mm Min. solid cardboard: 300 gr Equipment: Safety rules as described in CE and G.S: 2x Safety Mats and additional safety precautions at the machine. Pneumatic brake-clutch system with safety valve Automatic Central lubrication Control Panel with rotatable Arm Operation Modes: Single, Timer, Continuous Time setting at Control Panel: Time between opening and closing 1 – 6 seconds Second Timer for timed operation in closed position Batch Counter Hardened and ground ...
gebraucht
Maximum sheet format: 1420 x 1020 mm Minimum sheet format: 700 x 500 mm Maximum cutting force: 600 t Gripper margin: 18 – 22 mm Maximum output: 6000 sheets/hour Processable materials: Cardboard 100 – 1000 g/m² Corrugated board: F, E, B, C, F/F, F/E, F/B, E/E, E/B - Flatbed die-cutter with stripping station, inter-sheet inserter, and pre-stacking device, operator platform - 1 x Preparation table for external tool setup - 6 x Frames for stripping forms - 6 x Chase frames for cutting dies - 6 x Setup trolleys
gebraucht
Rotationswerkzeugschneider Ausgestattet mit: FFU-4055 flache Zuführeinheit RD-4055 Rotationswerkzeugfräser SPC-4055-Trenner
gebraucht
IBERICA SPDK-105 • Reference ID: PP-59169 • Category: Flatbed Die Cutter • Manufacturer: Iberica • Model: SPDK-105 • Year: 2013 • Condition: Good • Location: Europe • Availability: Immediately • Speed: 7,500 sheets/hour • Maximum sheet size: 750 x 1050 mm • Minimum sheet size: 350 x 400 mm • Maximum cutting area: approx. 740 x 1050 mm • Cutting pressure: approx. 300 tons • Suitable for carton: approx. 90 – 2,000 g/m² • Suitable for corrugated board: up to approx. 4 mm • Non-stop feeder system • Non-stop delivery system • Automatic sheet feeding • Central lubrication system • Touchscreen control panel • PLC-controlled operation system • Double ...
gebraucht
Reference ID: PP-56668 Category: Flatbed Die Cutter Manufacturer: Bobst Model: SPO 1600 Year: 1986 Speed: 6000 sheets/h Max. Size: 160 × 110 cm Min. Size: 60 × 52 cm Condition: Good Location: Europe Availability: Immediately
gebraucht
Max. Bogenformat: 740 x 1040 mm Min. Bogenformat: 350 x 400 mm Max. Produktionsgeschwindigkeit: bis ca. 8.000 Bg. / Std. Max. Stanzkraft: ca. 250 T Papier- Kartonstärke: 90 gr/m2 - 2.000 gr/m2 Max. Stärke Wellpappe. ca. 4 mm - 68.372 Betriebsstunden Standardmaschine mit dem vorhandenen Zubehör. - Palettenanleger (NonStop) - Ziehmarke links - Stripping Station - Nutzentrennung - Non-Stop Auslage min, 4 x Oberrahmen min. 4 x Unterrahmen 2 x Schnellspannrahmen
gebraucht
RABOLINI IMPERIA C MIT AUTOMATISCHEM ZUFÜHRGERÄT - Automatische Stanzmaschine mit Rabolini-Heißfolienaufsatz -Jahr: 1990 -Elektromagnetische Kupplung - Maximale Blechgröße: 800x1100 mm, maximale Stanzgröße 750x1050 mm. - Steuerkabine für Blatt-Geschwindigkeitsregelung ab 900 / 1600 Sh/Stunde - Wabenplatte zum Heißprägen, 2 Spalten und Rahmen zum Stanzen -Drei programmierbare Heizzonen aus der Steuerkabine -Rabolini Heißstanzfolieneinheit mit programmierbaren Zugwalzen -Maximale Druckleistung: 280 Tonnen -Alle Teile und Zubehörteile -Verfügbar im April
