Manufacturer: Bosch
Model: TFC 5532
Year of Manufacture: 2016
Cups:
4 x 50g, 6 x 50g
Designation:
Forming Machine
Technical Specification
Bottom Foil Sterilization:
Saturated Steam
Top Foil Sterilization:
Saturated Steam
Bottom Foils:
PS, PS-EVOH-PS, PS-EVOH-PE, PS Mono-Laminate foil, transparent and
multicolored
1.05 mm
Top Foils:
Pet-Alu-Pet, 9-12-9 µm
Filler 1:
Viscous products without particles
Filling range: 20 - 75 ml
Filler 2:
Liquid products without particles, hot filling 30-60°C
Filling range: 20 - 75 ml
Sorting Filler 1:
Yogurt two-colored; pudding single-colored or with swirl/marble
design
Sorting Filler 2:
Pudding or jelly single-colored
Performance:
4 x 50g: 28 cycles equals 40,320 cups / h
Punching:
4-set and 6-set punching
---------------------------------------------------------------
Important Control Functions
Cup Printing:
Laser (not included)
Cup Tightness Control:
Available, shutoff by date
Foreign Object Control:
X-ray scanner
Final Packaging
Full Wrap:
Full wrap for 4-set, with best-before-date printing via laser (Laser
not included)
Carton:
299 x 199 x 57 mm
Carton Labeling:
1 laser, short side of tray (Laser not included)
Packer:
4 x 6-set per cycle
6 x 4-set per cycle
Directly into trays or via collator
Additional Notes
- Maximum filling volume per filler: 75 ml
- Filling volume for current cup format: 45 ml
- Theoretically, two-layer dessert filling is also possible (needs
verification!)
