DANOBAT CG 51 600 CNC

Working wheel dimensions (od x id x width): Ø610x80xØ304.8 mm, cnc brand: FANUC, CNC brand: FANUC, CNC model: 21 Oi TB, Maximum length between points: 1060 mm, Max travel Z axis: 750 mm, Maximum length to be rectified: 600 mm, Height of points: 225 mm, Ø min/max to be rectified: 10 - 300 mm, Max. piece weight: 125 Kg, Max travel X axis: 325 mm, Grinding wheel speed: 45 m/s, Main engine power: 11 Kw, Workpiece head speed: from 30 to 1000 rpm, Workpiece holder head cone: MORSE 5, Power of workpiece head motor: 12 Nm, tailstock cone: MORSE 4, Travel of the tailstock quill: 70 mm, Hydraulic movement of the tailstock: 150 mm, Total power: 22 Kw, Long: 2300 mm, Tall: 1900 mm, Width: 2634 mm, Weight: 7750 Kg, Accessories: Cooling equipment with paper filter; MARPOSS meter, positioner and balancer;
Verkäufer Angebot Nr. resale 4584
