CNC Bearbeitungszentren DMG MORI DMU 125 P

x-Weg:1250 mm

y-Weg:880 mm

z-Weg:810 mm

Machine-Details
Stock-No. 1105-04052
Type of machine milling machining centers - universal
Make DECKEL-MAHO
Type DMU 125 P
Year of manufacture 2000
Type of control CNC
Storage location HAGUENAU FRANCE
Country of origin Germany
Delivery time after arrangement
Freight basis ex works, foundation

Technical details
x-travel 1250 mm
y-travel 880 mm
z-travel 810 mm
control TNC 430
spindle turning speed - stepless 20 - 18.000 U/min
power capacity at 100 % load 13,00 kW
tool taper SK50
table diameter 1.000 mm
a-axis 360,000 X 0,001 mm
swival range +/- +30 / -45 °
table load 1,00 t
feed X/Y/Z-axis 20 - 10.000 mm/min
rapid traverse X/Y/Z 24 m/min
toolpiece magazine: chain magazine 60 Stück
tool diameter 80 mm
tool diameter with 2 vacant positions 160 / 230 mm
tool length - max. 420 mm
total power requirement 35,00 kW
weight of the machine ca. 14,50 t
dimensions of the machine ca. 7,20 x 7,00 x H3,20 m
Additional information
5-axis SIMULTAN machining center with control HEIDENHAIN TNC 430;
NC swivel-rotary table Ø1.000mm; milling-head (hor./vert.);
reinforced 2-stage gearbox; coolant through the spindle, torque arm,
60-fold tool changer SK50; chip conveyor; probe HEIDENHAIN TS631;
