Doppelwandiger Edelstahltank mit Rührwerk 1500 Liter YOM 1991
Doppelwandiger Edelstahltank mit Rührwerk 1500 Liter YOM 1991
Edelstahlbehälter stehend 13.000 Liter - 2 Stück lagernd, Inklusive Isolierung und Rührwerk-Propeller. Bisher wurden sie für die Milcherzeugung verwendet. Cirka-Abmessungen: Durchmesser: 2.100 mm, Höhe inkl. Füße ca. 4.000 mm, Höhe Füße ca. 500 mm. Preis ab Werk, Zustellung möglich
Stn-; Kuipers Woudsend Steriltank. • Ladevolumen 3000 Liter, Bruto 3400 Liter • Betriebsdruck -1/5 bar. • Prüfdruck 7 bar. • Auslegungstemperatur 0/159°C. • Baujahr 2001. • Nettogewicht ±1100 kg • Inklusive vollständiger Dokumentation des Tanks.
325.000 Liter Edelstahl-Lagertanks mit Isolierung Ausgezeichneter Zustand SBS wird das komplette schlüsselfertige Projekt von der Demontage bis zur Vercharterung des Schiffes durchführen. Bitte beachten Sie, dass diese Tanks per Schiff transportiert werden müssen und sich Ihr Standort daher in der Nähe des Hafens befinden muss.
15,000 liter sugar tank/storage tank Characteristics: volume 15000 L Total length 4300 mm Cylinder length 3350 mm Total height 3600 mm diameter 2500 mm material V2A (AISI 304) 1.4301 Outside surface marbled Surface inside 2B=IIIC ground design horizontal Number of feet 6 Description MJ UNI-HOCH Tank crown: Inflow 2 mushrooms 2 x Cathedral Digital level measurement Floor slope 3% In front: Cone bottom Manhole 420 x 360 mm with magnetic safety device 2 x line connections - front and rear CIP Residual drain with butterfly valve DN 100 Below: 6 trumpet feet with domes - height adjustable on steel supports
22,000 liter sugar tank/storage tank Characteristics: volume 22000 L Total length 5500 mm Cylinder length 4500 mm Total height 3500 mm diameter 2500 mm material V2A (AISI 304) 1.4301 Outside surface marbled Surface inside 2B=IIIC ground design horizontal Number of feet 8 Description MJ UNI-HOCH Tank crown: CIP Management 3 x connections In front: 2 sight glasses Manhole 470 x 400 mm circuit Below: Residual drain pipe with disc valve 8 trumpet feet with domes - height adjustable on steel supports
3,800 liter rinsing milk tank/storage tank made of V2A Characteristics: volume 3800 L material V2A (AISI 304) 1.4301 Total height 2400 mm Cylinder height 1100 mm inner diameter 1850 mm Outside surface marbled Surface inside 2B=IIIC ground design vertical Number of feet 3 Description: MJ UNI-HOCH Topsoil: Flat floor with 3% slope threaded connector CIP ball Manhole Ø 540 mm vent nozzle Tank cylinder: 2 x step arches 2 x disc valve Underbody: Cone bottom drawn from outside to inside residual drain pipe 3 solid feet
2,000 liter rinsing milk tank/storage tank made of V2A Characteristics: volume 2000 L material V2A (AISI 304) 1.4301 Total height 2400 mm Cylinder height 1100 mm inner diameter 1300 mm Outside diameter 1600 mm Outside surface 2B=IIIC ground Surface inside 2B=IIIC ground design vertical insulation 150 mm Number of feet 3 Description: MJ UNI-HOCH Topsoil: Arched floor CIP ball manhole Tank cylinder: 2 x connection Underbody: Inclined cone bottom forward-drawn residual drain pipe with disc valve 3 feet with domes - height adjustable
