Spitzenlose Schleifmaschine # 4266 ESTARTA 301

Metallbearbeitungs- und Werkzeugmaschinen / Schleifmaschinen

Hersteller: ESTARTA

Modell: 301

Maschinentyp: Spitzenlose Schleifmaschine # 4266

Eintrags-Nr.: 167450627

Anzahl: 1

Datum: 03.07.2025

Baujahr: Gebrauchtmaschine

Standort: Land-es Spanien

Preis:


Positionsnummer des Verkäufers: 4266

Hydraulic automatic plongee, plongee bowler, grinders, OPTIONAL: lead, CNC, fairing, gearbox elimination and speed variator adaptation for drag wheel, automatic centralized lubrication, 1 Year Warranty / Plongee automatic hydraulic, Porta plongee rules, Saucers wheel holder, OPTION: Porta rules enfilade, cnc, protection, eliminating gearbox and variable speed adjustment for wheel drive, 1 year warranty, Grinding wheel gap : 1.5 / 50 mm, Max.width of wheel in feed grinding : 125 mm, Working wheel dimensions (od x id x width) : 325 x 175 x 125 mm, Øext.min. working wheel : 220 mm, Max. profile depth of the working wheel: 8 mm, Infeed (auto / manual): Automatic / Automatic, Driving wheel dimensions (od x id x width) : 220 x 125 x 125 mm, Øext.min. driving wheel : 165 mm, Working wheel motor power : 7,5 Kw, Driving wheel motor power: 0.75 Kw, Angle of inclination of the working grinding head: +/- 5º, Angle of inclination of the drive wheel head: -2/+5º, Long: 1.520 mm, Width: 1.020 mm, High: 1.260 mm, Weight: 1.550 Kg.
Diese Maschine auf Facebook
Diese Maschine als verkauft

Anfrageformular

Sind Sie Händler?

Bitte senden:

Gesuchsanfrage?

Kopie an Sie?

Eingabedaten speichern?

Hydraulic automatic plongee, plongee bowler, grinders, OPTIONAL: lead, CNC, fairing, gearbox elimination and speed variator adaptation for drag wheel, automatic centralized lubrication, 1 Year Warranty / Plongee automatic hydraulic, Porta plongee rules, Saucers wheel holder, OPTION: Porta rules enfilade, cnc, protection, eliminating gearbox and variable speed adjustment for wheel drive, 1 year warranty, Grinding wheel gap : 1.5 / 50 mm, Max.width of wheel in feed grinding : 125 mm, Working wheel dimensions (od x id x width) : 325 x 175 x 125 mm, Øext.min. working wheel : 220 mm, Max. profile depth of the working wheel: 8 mm, Infeed (auto / manual): Automatic / Automatic, Driving wheel dimensions (od x id x width) : 220 x 125 x 125 mm, Øext.min. driving wheel : 165 mm, Working wheel motor power : 7,5 Kw, Driving wheel motor power: 0.75 Kw, Angle of inclination of the working grinding head: +/- 5º, Angle of inclination of the drive wheel head: -2/+5º, Long: 1.520 mm, Width: 1.020 mm, High: 1.260 mm, Weight: 1.550 Kg.
Verkäufer Angebot Nr. resale 4266
Diese Maschine auf Facebook
Diese Maschine als verkauft
Geprüfter
Händler

Verkäufer


verified user

RESALE Anbieter seit 2016

Für mehr Infomationen über den Verkäufer, bitte eine Anfrage senden und Option "Kopie an Sie" auswählen.
