Intern table clamp, 1000Kg hoist, Fairing, CE | Throughfeed work rest,
block and tackle for 1.000kg, Machine casing, CE, Ø grinding wheel
dimensions (od x id x width): Ø 650 x Ø 304,8 x 500mm, Ø min / max
to grinding: 3/200 mm, Regulating wheel width: 500 mm, Regulating
wheel speed nº: Infinite, Min / max regulating wheel speed (r.p.m.):
10/255 r.p.m., Dressing (auto / manual): Automatic / Automatic,
Diamond dressing speed: 255 r.p.m., Lubrication (auto / manual):
Automatic / Automatic, Control type ((cnc / manual): CNC, Cnc brand:
FANUC, Cnc model: Oi - TF, Infeed (auto / manual): Automatic /
Automatic, Regulating wheel dimensions (od x id x width): Ø 350 x Ø
203,2 x 500mm, Grinding wheel width: 500 mm, Maximum infeed grinding
length: 500 mm, Motor power grinding wheelhead: 55 Kw, Power hydraulic
motor: 3 Kw, Total power: 60 Kw, Voltage: 220 / 380V, Long: 2.300 mm,
Width: 2.800 mm, High: 2.100 mm, Weight: 15.000 Kg, Accessories
included: Intern table clamp, 1000Kg hoist, fairing, CE | Throughfeed
work rest, block and tackle for 1.000kg, Machine casing, CE
Spanien
fuente de cantos
