Homogenisatoren GEA NIRO SAVI Ariete NS2006

Description Item #8857 – HOMOGENISER Manufactured by GEA NIRO SOAVI Model Ariete NS2006 L Energy Current owner purchased refurbished by GEA in 2013 original year believed to be 2006 suitable for pharma products MAX Viscosity UP TO 500 cP MAX Working Pressure 1500 bar Flow Rate Type F F = Fixed MAX Flow Rate 35 L/h @ 50 Hz MIN Feed Pressure 4-5 bar MAX Backpressure 5 bar MAX Product Temperature <.90 °C MAX CIP / SIP Temperature 140 °C Ambient Conditions 40°C MAX; R.H. 40%; 1000 m above sea level TECH FEATURES - COMPRESSION HEAD Type MONO-BLOCK (VHP) MaterialSAF 2507 No. of Plungers 2 Plunger Material CERAMIC Plunger Diameter 10 mm Plunger Stroke 40 mm Pumping Valve Type PVB 1/2" Pumping Valve Material STELLITE GR20 Pumping Valve Seat Material STELLITE GR20 Overpressure Valve Type NSSRLV HP Overpressure Valve Setpoint 1650
Verkäufer Angebot Nr. resale 8857
