VERTICAL MIXER, 10 m3 capacity, total height approx 5.400 mm including
transmission group, max Ø 2.300 mm., constructed in painted
electro-welded carbon steel., inner auger diam.350 mm. lower loading
hopper with safety grid and sampling shutter, complete with anti-dust
cover, mm.600x500, pulley and belt transmission, protected by carters,
inspection doors with safety limits, cleaning hinged door on bottom of
cone for complete discharging, with safety opening, side discharging
pipe to big bag with valve at 2.500 mm from ground, max electric level
indicator, paddle type, automatic greasing kit, 11 kw drive, complete
with control panel., electric voltage: 400 V, 50 Hz, auxiliaries a.c.
24 V, CE compliance and instruction manual, Possible additions:
horizontal loading screw and hopper + cyclone on top + collector with
dust sleeves piping + bag holding structure+bag weighing station + PLC
for automation with other machines., installed power - used power in
work: about 60-65% : 11, capacity: 10.000 lt
