CNC Drehmaschinen HARDINGE Elite 27 MS

Excellent condition - Fully operational - Loading / Transport possible!

Twin spindle
Swing over bed: 530 mm
Turning length: 330 mm
X-Axis travel: 210 mm
Z-Axis travel: 310 mm
Rapid traverse: 30 m/min
Spindle speed: 8000 Rpm
Spindle configuration: A2-4, 5C
Spindle bore: 27 mm
Turret type: VDI 25
Live tool speed: max. 6000 Rpm
Number turret positions: 16
Control: GE Fanuc Series 18i-TB
Incl various tool holders a.o. 6x driven toolholders
Note! No tooling
Bar Feeder: BARLOAD
Type: Hydrafeed BA 65
S/N: 16080043
Year 2009
Bar length: 1200 mm
Bar diameter: 5-65 mm
Bar capacity: 10 pcs (65 mm)
Dimensions: 1910x1000x1250 mm
Weight: 320 kg
Verkäufer Angebot Nr. resale 169482772
