Name KAMA ProFold 74
ID PP-46669
Category Folder Gluer
Manufacturer -
Model ProFold 74
Year 2022
Color -
Impression -
Working Hours -
Speed 150 m/min
Max. Size -
Min. Size -
Condition Good
Location Europe
Availability Immediately
Description
• Max. mechanical speed 150 m/min
• Max. case format 740 mm (width)
• Min. case format 100 mm x 120 mm
• Min. weight 100 gsm
• Max. weight 600 gsm
• Max. stack height 300 mm
• Programmable logic controller OMRON PLC, 8 channels
• Power consumption 5.5 kW
• Compressed air supply 0.6 MPa
• Net weight 1,800 kg
• Dimensions L x W x H 5,700 x 1,000 x 1,400 mm
• The transport conveyor is equipped with:
an OMRON programmable controller with 8 inputs (3 channels)
an interface for hot-melt gluing devices
• a color touch screen
• pressure rollers
the following folding tools: (2 large folding shoes, 2 small folding
shoes, 1 folding pocket]
2 blower nozzles
The outletThe hot-melt gluing device
The standard hot-melt gluing device is supplied by "Robatech". This
system has 4 inputs.
As standard, 2 hot-melt gluing nozzles with the necessary piping are
supplied. In addition, the gluing device can be equipped with up to 4
gluing nozzles (option). Of course, it is possible to equip the KAMA
ProFold 74 folder gluer with cold gluing devices or other suppliers
(HHS, Nardsan or Leary). A personalized quote can then be made.
• The KAMA ProFold 74 folder gluer allows you to stand out by
expanding your product offering and reaching a wider customer base.
Depending on the options selected, the machine can produce
high-quality products, such as
- Folding with shoe fold, folder folding, folding flaps downwards or
upwards
Hot or cold gluing
Folding of folders "with capacity"
- Depositing flat objects or samples
"Pick and place" of objects or samples that are not flat
- Dispenser and deposit of double-sided
- In-line creasing and perforation, directly in the machine
The KAMA Profold 74 can process a wide range of products in the field
of commercial printing or packaging:
- Presentation folders
- Envelopes with double-sided gluing (option)
- Cases, with straight flap or with automatic bottom (option)
- Greeting cards / holiday cards
- Folders with capacity (option)
Card envelopes (option)
... and many other things...
The flexibility of this machine allows you to quickly conquer new
markets.
