KEMMERICH VD 3000 UF-SH-520-S

Manufacturer: Kemmerich

Model: VD 3000 UF-SH-520-S

Type of Machine: Double Decoiling Reel / Uncoiler

Year of Manufacture: 1999

Technical Specifications:

- Band width: 100 to 520 mm
- Band thickness: 0.5 to 2.5 mm
- Maximum coil weight: 3,000 kg
- Spreading range diameter: 470 to 520 mm
- Maximum coil outer diameter: 1,600 mm
- Maximum band speed: 25 metres per minute
- Reel crown rotation speed: 1 to 15 rpm
- Drive power: 2.6 kW
- Connection voltage: 480 V AC, 60 Hz
- Rated current: 16 A
- Control voltage: 24 V DC
- Cross shaft height: approximately 1,250 mm
- Maximum load capacity per nameplate: 3,000 kg
