Manufacturer: Lezzeni
Model: CLV/C 200
Year of Manufacture: 2008
CE certified: Yes
Number of spindles: 32
Spindle pitch: 200 mm
Max. twisting spindle speed: 5,000 RPM
Max. stroke (hub): 420 mm
Spindle type: HZ 55/21
Electrical Data
- Mains supply: 400 V - 3 phase - 50 Hz
- Nominal current draw: 12 A
- Main motor current: 12 A
Motors and Drive
- Spindle drive motor: 4 kW - 4 pole - 230/400 V - 50 Hz
- Stroke control motor: 0.09 kW - 6 pole - 230/400 V - 50 Hz
- Spindle drive belt: TFL 7S 8460 x 40 mm
- Yarn brake type: 003353
Machine Dimensions
- Machine length: 5,405 mm
- Machine width: 1,800 mm
- Machine depth: 700 mm
