CNC controller: FANUC Professional 5
Axes
X-axis travel mm: 550
Y-axis travel mm: 1000
Z-axis travel mm: 500
C-axis degrees: 360 (continuous rotation) / rotary encoder
A-axis degrees: 150 (+30 120º) rotary encoder
Feed rates m/min: X:32; Y,Z:40;
Rapid traverse m/min: X,A,C:48; Y,Y:50; A,C:18
Worktable
Table dimensions mm: 500
Maximum workpiece size (D x H) mm: 650x500
Max. workpiece weight kg: 350
T-Slot version: 4x185H8
Spindle
Spindle speed rpm: 20000
Tool system
Tool holder: HSK-A63
Tool magazine slots: 323
Tool changer: pinza doble
Max. Tool Diameter: 70
With occupied neighboring places mm: 140
Tool Magazine: Matrix
Max. Tool Length mm: 300
Max tool weight kg: 8
Equipment
Electronic Handwheel
Chip conveyor
Custom Macro common variables (100)
Synchronized tapping
Preparación para trabajar con robot
Robot EROWA
Helical interpolation
Custom Macro common variables (100)
Machine running times
Spindle Working: 0h (Retrofited)
Basic machine dimensions / weight
Length mm: 3550
Width mm: 2900
Height mm: 3200
Weight kg: 15700
Deutschland
