Drehdurchmesser:420 mm
Drehlänge:780 mm
Drehzahl:3500 1/min
Machine-Details
Stock-No. 1105-04034
Type of machine CNC Lathe
Make MORI SEIKI
Type SL 35
Year of manufacture 1991
Type of control CNC
Storage location FRANKREICH
Country of origin Japan
Delivery time CALL ME
Freight basis EX WORK
P
Technical details
turning diameter 425 mm
turning length 780 mm
control FANUC 15t
turning diameter over bed 600 mm
turning dia. over face-slide 420 mm
centre distance 890 mm
travel -x axis 240 mm
travel -z axis 855 mm
spindle turning speed range 3500 U/min
spindle bore 80 mm
turret (x-stations) 12-fach
shaft cross cut 35
Shank diameter 60 mm
rapid traverse longitudinal 12000 mm/min
rapid traverse cross 12000 m/min
tailstock travel 100 mm
engine output 22/18.5 kW
total power requirement 49 kVA
weight of the machine ca. 8 to
Additional information
Machine in VERY good condtion with chip conveyor AND CNC FANUC 15 TF
Verkäufer Angebot Nr. resale 165501715
Frankreich
