Stratasys Objet24 Specifications
Build Volume
- 234 × 192 × 148.6 mm (9.21 × 7.55 × 5.85 in)
Layer Thickness & Resolution
- Layer Thickness: 28 microns (0.028 mm)
- XY Resolution: 600 dpi
- Z Resolution: 900 dpi
Accuracy
- ±0.1 mm
Materials & Technology
- Technology: PolyJet (material jetting with UV curing)
- Materials: VeroWhitePlus™ (model), FullCure 705 (support)
Printer Size & Weight
- Dimensions: 825 × 620 × 590 mm (32.5″ × 24.4″ × 23.2″)
- Weight: ~106 kg (234 lbs)
Power & Connectivity
- Power Requirements:
- 100–120 VAC, 50–60 Hz, 7 A
- 220–240 VAC, 50–60 Hz, 3.5 A
- Network: Ethernet (TCP/IP)
