TSUGAMI B0206E-II Sliding Headstock CNC Lathe
TECHNICAL FEATURES:
Year: 2014
NC Type: FANUC series 32i-B
Number of axes: 6
X1 Axis Fast Feed Speed: 24000 [mm/min]
X2 Axis Fast Forward Speed: 24000 [mm/min]
Z1 axis fast feed speed: 32000 [mm/min]
Z2 axis fast feed speed: 32000 [mm/min]
Y1 Axis Fast Feed Speed: 15000 [mm/min]
Y2 Axis Fast Feed Speed: 15000 [mm/min]
Maximum diameter in bar: 20 [mm]
Minimum speed. Spindle: 200 [rpm]
Maximum speed Spindle: 10000 [rpm]
C-axis indexing accuracy: 0.001 [°]
Spindle power: 3.7 [kW]
Minimum speed. Spindle: 200 [RPM]
Maximum speed Spindle: 12000 [rpm]
C-axis sub-spindle indexing accuracy: 0.001 [°]
Spindle power: 2.2 [kW]
Number of end device positions: 8
Number of comb positions 1 : 5
Number of motorized comb stations 1 : 3
Comb Turning Tool Speed 1: 8000 [rpm]
Number of counter-operation positions: 8
Number of counter-operation motorized positions: 4
Counter Rotating Tool Speed: 8000 [rpm]
Max. section Tool holders: 12 x 12 [mm]
Working time: 9132 [h]
Weight: 1750 [Kg]
EQUIPMENT INCLUDED:
x7 Rotating Tool Holders
x1 Spinning Cannon
x1 Coin Collector
x1 Parts Conveyor Belt
x1 Workpiece Ejector
x1 Chip Conveyor
x1 watering tray
x1 IEMCA ELITE 220 E / 32 XL bar feeder
x1 fire-fighting device (to be checked by the buyer by a qualified
body)
x1 Electrical Transformer
x1 3-color status lamp
Machine visible under tension for testing at our premises, by
appointment.
Price excl. VAT on request, including truck loading.
Possibility of shipping throughout France as well as
internationally.
More photos and details on request.
Technical description for information purposes only, without
obligation on our part.
Machines similar to the lathes of the citizen, nomura, tornos, miyano,
index, traub, star but also machining center, milling and grinding
machine
