Watter-Schneider WATERJET

2004 WaterJet

Watter Cutter

Technical Condition: operational

Manual: -

Specifications:

Cutting material: Water+abrasive

Number of nozzles: 2 (programmable 1 nozzle)

Water consumption: 3.6-7.2 l/min.

Abbrasive consumption: 250-400 g/min.

Water pressure: 4000 bar

Sheet thickness: max. 100mm

Sheet dimensions: 2000 x 6000 mm

Space requirement:

4900 mm wide

7200 mm long

3500 mm high

High speed 6000 mm/min

Cutting speed: 5-3000 mm/min

Drives: Servomotors

Combined power: 37-75 kW.

Programming circuit: E.C.S CNC-1801

Programmable on the machine tool and has a programming workstation.

Programme: LogoTag 2003 and MagicTool

Year of construction: 2004
