Vierseitenhobelmaschinen WEINIG QUATTROMAT 23 P

Excellent condition - Fully operational - Loading / Transport possible!

Working width 13 to 230 mm

Working height 6 to 120 mm

Number of spindles 4

Motor power of dressing spindle 4 to 7.5 kW

Motor power of vertical spindles 5.5 to 11 kW

Motor power of upper spindle 4 to 11 kW

Feeder motor power 1.5 kW

Diameter of spindles 40 mm

Tool flight circles of throat spindles 125 to 200 mm

Adjustment range of spindles axial 30 mm

Adjustment range of dressing spindle 5 mm

Feed rate 8 m per minute

Diameter of feed rollers 140 mm

Width of feed rollers 2 x 50 mm

Width of roller in outfeed table 50 mm

Adjustment range for dressing table and ironing ruler 10 mm

Height of right stops 60 mm

Length of dressing table 2000 mm
Verkäufer Angebot Nr. resale 169368190
