Autoplatine WUPA PS 5.2 Automatic die-cutting and creasing machine

Format: 920×1300 mm

Ausstattungen:
Maximum sheet size 920×1300 mm, minimum size 560×1300 mm
opening width within frame 920×1310 mm, maximum die size 910×1300 mm
maximum die-cutting area 900×1300 mm, maximum gripping edge = 16 mm, minimum gripping edge = 8 mm
maximum card thickness 3 mm (also with micro-flute and flute zero), maximum compressed air pressure 500 t, maximum stroke rate 5500/h
infeed stack height 1100 mm, outfeed stack height 1100 mm, main motor power 18 kW, main motor power consumption 17 kW, speed 5500 strokes/h.
Machine dimensions (L x W x H): 6835 mm x 3580 mm x 2690 mm. Total weight of the machine including the insert approx. 30 t, weight of the machine without the insert approx. 29 t
Verkäufer Angebot Nr. resale 41662
