TECHNICAL DATA:
Machine type: Four Side Seal, Transverse Zipper Sealed, Side Seal
Pouch Making Machine
Application: production of high-quality laminated flexible packaging
pouches with zipper and punching options.
PRODUCT TYPES:
• Four side seal pouches
• Quad seal pouches
• Side seal pouches
• Transverse zipper pouches
• Gusset pouches
• Bottom stick hole pouches
• Micro-perforated pouches
• Handle hole pouches
• Round corner pouches
MATERIALS:
• LDPE
• CPP
• MCPP
• AL
• Nylon
• PP
• Laminated film structures
MAIN TECHNICAL INFORMATION:
Material thickness: 60–250 μm
Max. web width: 1300 mm
Max. roll diameter: 800 mm
Core diameter: 3” and 6”
Max. pouch width, quad seal: 400 mm
Max. pouch length: 1000 mm
Eye mark accuracy: ±1 mm
Machine speed: 15–65 pcs/min
Material speed: 40 m/min
Main power: 400V, 50Hz, 3 phase
Installed power: 100 kW
Machine weight: approx. 18,000 kg
Machine size: 33,500 × 4,200 × 1,800 mm
POUCH SIZE RANGE:
Quad seal / side welded width: 180–400 mm
Gusset depth: max. 80 mm
Minimum gusset depth: 30 mm
Bag length: 360–1000 mm
UNWINDING SECTION:
• Air shaft unwinding
• Magnetic powder brake
• Dancing roller tension control
• Servo-driven unwind system
PERFORATION SYSTEM:
• Micro perforation unit
• Wheel type perforation
• Additional perforation holes
• Same type as existing machine configuration
FOLDING SYSTEM:
• Four side seal / quad bag folding wheel section
SEALING AND COOLING SYSTEM:
Mechanical press sealing system:
Quad seal longitudinal sealing: 2 groups, 1010 mm
Quad seal longitudinal cooling: 2 groups, 1010 mm
Cross sealing station: 6 sets
No. 1: K-seal
No. 2: Gusset filling sealing
No. 3: Cross seal, 740 mm length / 60 mm width
No. 4: Cross seal, 740 mm length / 60 mm width
No. 5: Cross seal, 740 mm length / 60 mm width
No. 6: Cross cooling, 740 mm length / 60 mm width
Additional 5 mm sealing section, upper and bottom
PUNCHING SYSTEM:
Tear slit / notch puncher
3-hole handle puncher
Handle puncher: 20 × 80 mm, 3 sets
Hole sizes: • 3 holes Ø20 mm
• 20 × 80 mm
• 24 × 77 mm
Round corner puncher: 2 sets
Puncher supports: 3 sets
Bottom stick hole puncher: • 12 mm, 8 pcs
• 16 mm, 8 pcs
Vacuum system for punch waste removal
DRIVE SYSTEM:
Main motor: 3.5 kW
Back draw roller servo: 3.5 kW
Front draw roller servo: 3.5 kW
Middle draw roller servo: 3.5 kW
Longitudinal independent sealing servo: 5 kW × 2
Unwind servo motor: 1.5 kW × 1 / 3.5 kW × 1
Tension control servo: 3.5 kW × 1
Flying knife servo: 1.5 kW × 1
Manipulator sucker drive: 0.75 kW × 1
Finished product carrier counting drive: 0.75 kW × 1
CONTROL SYSTEM:
• PLC control
• 10” touch screen
• Suitable for printed and unprinted bags
• 16 temperature control zones
• Individual temperature display
• Temperature tolerance: ±2°C
• High-sensitive eye mark sensor
• Adjustable eye mark position
STACKING SYSTEM:
• Simple type stacking table
• Static removal system
• Automatic stop when machine stops
• Alarm for bag output range: 25–100 bags
• Step motor belt control
• Belt width: 60 mm
• Adjustable batch and belt length
SAFETY SYSTEM:
• Safety light curtain
• Emergency pulling rope
• Emergency buttons every 2 meters
• Individual emergency control
INCLUDED OPTION:
ZIPPAK transversal zipper attachment
Transversal zipper unwinder and rewinder
Innolock / Velcro zipper capability
Tooling for 3 zipper sizes: • 180–220 mm
• 230–300 mm
• 310 mm
Micro-perforation holes
Bottom stick hole puncher
Trim rewinders: 3 sets
Chiller: 1 set
Spare K-type sealing knives: 3 sets
