CNC Bearbeitungszentren DMG DECKEL MAHO DMC 635

x-Weg:635 mm

y-Weg:510 mm

z-Weg:460 mm

Machine-Details
Stock-No. 1105-04041
Type of machine Machining Center - Vertical
Make DECKEL MAHO DMG
Type DMC 635 V
Year of manufacture 2006
Type of control CNC
Storage location HAGUENAU FRANCE
Country of origin Germany
Delivery time IMMEDIATELY
Freight basis EX WORK
Price

Technical details
x-travel 635 mm
y-travel 510 mm
z-travel 460 mm
table-size 790 x 560 mm
spindle taper ISO SK 40
turning speed range 12000 1/min
feeds longditudinal/cross/vertical 1 - 30000 mm/min
rapid motion -longitudinal/cross/vertical 30 m/min
no. of tools in magazin 20
workpiece diameter at full load 80 mm
wotkpiece diameter with 2 vacant positions 140 mm
workpiece length 300 mm
weight of tools max. 7 kg
table load 600 kg
spindle drive 9 / 11 kW
control HEIDENHAIN TNC 530I
total power requirement 30 kVA
Additional information
cnc HEIDENHAIN I TNC 530
MAGSIN POSITIONS 32 SK 40
el. handwheel,
12000 RPM
CTS TROUGHT THE SOINDEL
20 BARS PAPIER FILTER SYSTEME
Verkäufer Angebot Nr. resale 165829186
