Ø grinding wheel dimensions (od x id x width): Ø 406 x Ø 203 x 200
mm, Ø min / max to grinding: 1.5 / 100 mm, Regulating wheel width:
200 mm, Min / max regulating wheel speed (r.p.m.): 10/250 rpm, Control
type ((cnc / manual): Manual, Infeed (auto / manual): Automatic /
Automatic, Regulating wheel dimensions (od x id x width): Ø 270 x Ø
140 x 200 mm, Grinding wheel width: 200 mm, Maximum infeed grinding
length: 200 mm, Motor power grinding wheelhead: 15 kW, Long: 2020 mm,
Width: 1300 mm, High: 1420 mm, Weight: 4200 Kg, Accessories included:
Automatic Hydraulic Plongee, Diamond Compensator, Plongee Porter,
Saucer Cymbal, Speed Variator for the traction wheel OPTIONAL:
Lead-in Trimmer, Cowling, Automatic Centralized Lubrication, 1 Year
Warranty / Automatic hydraulic Plongee, Diamond compensator, Porta
plongee rules , Saucers wheel holder, OPTION: Porta rules enfilade,
protection,, automatic lubrication system, 1 year warranty
Spanien
