AUTOMATIC VERTICAL BINDING BALER, for FILM, WOVEN PP, PET, RIGID AND
SOFT PLASTICS, PAPER, CARDBOARD and more, 100 Tons ca. pressing force,
45 kw drive, complete with oil heating and cooling systems,
proportional pressure flow controller, adjustable channel pressure,
Bale size LxWxH 1.100x720 mm (adjustable length), Filling hopper size
1.100 x 1.600 mm., Average throughput rate, - with 30 kg/m3 materials
6-8 Ton/h, - with 50 kg/m3 materials 10-12 Ton/h, - with 120 kg/m3
materials 18-20 Ton/h, 5 vertical-wire binding, upper and lower
photocells to control material feeding feeding, Cycle with no
material, no twisting : 22 ca, Pre-press flap with 2 x 20 Ton force,
Exchangeable bottom plate in hardox in channel and chamber, Baler
weight ca.27.000 kg., General features, common to all balers:,
Construction ìn sturdy carbon steel with top EU components., Compact
and easy to use, Automatic binding, Fully automatic with adjustable
parameters on touch screen panel., A MODEM is installed for quick and
cheap remote assistance., PRE-PRESSING : to increase production per
cycle and bale size. No cutting knife to sharpen. Bales are heavier
and more compacted for better storing., HYDRAULIC UNIT : compact, on
the rear of the baler. A block contains all valves and pipes., AXIAL
DISPLACEMENT PISTON PUMP, mounted outside of the tank: low noise,
short adjustment time, service friendly, high speed, 100% torque
transfer., CARTRIDGES : the distribution block control the most
important movements: oil temperature remains lower, no pressure
surges., PRE PRESS FLAP and PRESS RAM can move simultaneously, so
saving time, INCREASED EFFICIENCY : little pressure loss + lower
energy consumption + higher capacity., OPTIONAL OIL COOLING SYSTEM : a
thermostat will control oil temperature and automatically activate the
cooler., OIL TEMPERATURE and OIL LEVEL are controlled: the baler will
turn off if the thresholds are reached., WEAR and TEAR on SEALS is
reduced and possible prevented by the ball joint which fastens the
cylinders, A SIEMENS S7 1200 touch screen panel controls the machine
and all of its automatic functions (the machine can always be used in
manual mode), availability: ca 6 months from confirmation, options
available: perforator, intermidiate hopper, conveyor feed hopper, exit
table for bale, support 50 cm., wire coil stand, capacity: 6-20 Tons/h
depending on materials and feeding rate, type: pre-press
Italien
ponderano
