AUTOMATIC VERTICAL BINDING BALER, for FILM, WOVEN PP, PET, RIGID AND
SOFT PLASTICS, PAPER, CARDBOARD and more, 120 Tons ca. pressing force,
90 kw drive, complete with oil heating and cooling, proportional
pressure flow controller, Filling hopper 1.100 x 1.600 mm., Bale size
LxWxH 1.100x720 mm (adjustable length), Average throughput rate, -
with 30 kg/m3 materials 6-8 Ton/h, - with 50 kg/m3 materials 11-13
Ton/h, - with 120 kg/m3 materials 19-22 Ton/h, 5 vertical-wire
binding, Cycle with no material, no twisting : 21 ca, Pre-press flap
with 2 x 26 Ton force, Exchangeable bottom plate in hardox in channel
and chamber, Machine weight ca 28.500 kg, oil tank capacity : 1.500
kg, General features, common to all balers:, Construction ìn sturdy
carbon steel with top EU components., Compact and easy to use,
Automatic binding, Fully automatic with adjustable parameters on touch
screen panel., A MODEM is installed for quick and cheap remote
assistance., PRE-PRESSING : to increase production per cycle and bale
size. No cutting knife to sharpen. Bales are heavier and more
compacted for better storing., HYDRAULIC UNIT : compact, on the rear
of the baler. A block contains all valves and pipes., AXIAL
DISPLACEMENT PISTON PUMP, mounted outside of the tank: low noise,
short adjustment time, service friendly, high speed, 100% torque
transfer., CARTRIDGES : the distribution block control the most
important movements: oil temperature remains lower, no pressure
surges., PRE PRESS FLAP and PRESS RAM can move simultaneously, so
saving time, INCREASED EFFICIENCY : little pressure loss + lower
energy consumption + higher capacity., OPTIONAL OIL COOLING SYSTEM : a
thermostat will control oil temperature and automatically activate the
cooler., OIL TEMPERATURE and OIL LEVEL are controlled: the baler will
turn off if the thresholds are reached., WEAR and TEAR on SEALS is
reduced and possible prevented by the ball joint which fastens the
cylinders, A SIEMENS S7 1200 touch screen panel controls the machine
and all of its automatic functions (the machine can always be used in
manual mode), availability: ca 6 months from confirmation, options
available: perforator, intermidiate hopper, conveyor feed hopper, exit
table for bale, support 50 cm., wire coil stand, capacity: 6-22 Tons/h
depending on materials and feeding rate, type: pre press
Italien
ponderano
