Mixaco CM-2000 D - Cold mixer
Verfahrenstechnik
Keyence WM 3000 Messgeräte
gebrauchtGeprüfter Anbieter
Preis anfordern
Direkt an den Anbieter
1 / 4
Technische Daten
· ID 168750542Verfahrenstechnik
- Zustand
- gebraucht
- Baujahr
- 2020
- Standort
- Germany
Identifikation
HerstellerKeyence
ModellWM 3000
Positionsnummer8533220
Technik
Stückzahl1
Beschreibung
Manufacturer: Keyence
Model: WM 3000
Year of Manufacture: 2020
Type of Machine : 3D coordinate measuring system
The device has already been upgraded to Windows 11
Measurement Specifications
- Maximum Measuring Range (W x D x H) 10000 x 3500 x 5000 mm
- Guaranteed Accuracy Range (W x D x H) 3000 x 1500 x 1500 mm
- Measuring Accuracy +/- (28 + 5L/1000) micrometers
- Repeatability +/- 10 micrometers
Minimum Display Resolution
- Distance Resolution 0.001 mm
- Angle Resolution 0.001 degrees
Camera Unit Rotation
- Theta Rotation (Pan) +/- 90 degrees
- Tilt Rotation +/- 30 degrees
Connectivity
- External Input Voltage-free input, 2 inputs
- Bluetooth Bluetooth 5
- USB USB 3.0
- Infrared Communication 945 nm
Power Supply
- Power Supply Type Supplied via dedicated power supply unit
- Rated Voltage DC 24 V
- Power Consumption 1.7 A
Environmental Conditions
- Operating Temperature +10 to 35 degrees C
- Relative Humidity 20 to 80 % relative humidity, non-condensing
Physical
- Weight Approx. 13 kg
Find more here - .ucymachines/
Contact us at - sales@ucymachines
Model: WM 3000
Year of Manufacture: 2020
Type of Machine : 3D coordinate measuring system
The device has already been upgraded to Windows 11
Measurement Specifications
- Maximum Measuring Range (W x D x H) 10000 x 3500 x 5000 mm
- Guaranteed Accuracy Range (W x D x H) 3000 x 1500 x 1500 mm
- Measuring Accuracy +/- (28 + 5L/1000) micrometers
- Repeatability +/- 10 micrometers
Minimum Display Resolution
- Distance Resolution 0.001 mm
- Angle Resolution 0.001 degrees
Camera Unit Rotation
- Theta Rotation (Pan) +/- 90 degrees
- Tilt Rotation +/- 30 degrees
Connectivity
- External Input Voltage-free input, 2 inputs
- Bluetooth Bluetooth 5
- USB USB 3.0
- Infrared Communication 945 nm
Power Supply
- Power Supply Type Supplied via dedicated power supply unit
- Rated Voltage DC 24 V
- Power Consumption 1.7 A
Environmental Conditions
- Operating Temperature +10 to 35 degrees C
- Relative Humidity 20 to 80 % relative humidity, non-condensing
Physical
- Weight Approx. 13 kg
Find more here - .ucymachines/
Contact us at - sales@ucymachines
