Presse ALPHATECH RPS4000

2004 Alphatech Model RPS4000

Description:

Electro-hydraulically driven frame press

Series: Type:RPS 4000

Date of manufacture:12.2003

plunger force From approx. 4000 kN kN

plunger force Up to approx. 916 kN kN

plunger stroke approx. 600 mm

Installation table - column max. 1050 mm

Max. plunger rapid speed approx. 600 mm/sec

Max. Splunger working speed approx. 41.7 mm/sec

Max. Return speed approx. 440 mm/sec

Table surface (WD) approx. 900965 mm

Full volume Hydrauliko! HLP 46 approx. 5300 litres

Main drive power 290 kW+ 255kW + 130kW

Control voltage 230 VAC/ 24VDC

Operating voltage 400 V /50 Hz

Colour scheme:

System RAL 1014

Control cabinet, control panel and hazard labelling RAL 2002
