Machine: Dainippon Screen PlateRite 4300S (2013)
Type: 4-page Thermal CTP Platesetter
Laser Technology: 32-channel infrared laser diode
Maximum Plate Size: 830 x 660 mm (32.6" x 25.9")
Minimum Plate Size: 324 x 370 mm (12.8" x 14.6")
Plate Thickness: 0.15 to 0.3 mm (5.9 to 11.8 mil)
Productivity: Up to 21 plates per hour (at 2,400 dpi)
Resolutions: 1200, 2400, 2438, 2540, 4000 dpi
Loading Configuration: Manual loading (optional auto-loader
compatible)
Dimensions (W x D x H): 1750 x 1030 x 1178 mm (68.9" x 40.6" x
46.4")
Weight: Approx. 650 kg (1,430 lbs)
Luxel T6300 CTP S
