Manufacturer: ESC
Model: ESC-AT-60PD
Type of Machine : Screen Printing Machine
Semi-automatic, universal, digitally controlled precision screen
printing machine for flexible and rigid materials up to 200 mm
material thickness
STANDARD EQUIPMENT/FEATURES
- Programmable PLC control system
- User-friendly operation via touch screen
- High-quality linear guides for smooth, low-noise motion
- Vertical, motor-driven screen frame lifting with synchronized
stripping motion
- Precision print head with pneumatic lift for screen change and
cleaning
- Digital input of desired print parameters:
- Speed for print and flood squeegee
- Print height
- Print stroke length
- Neutral position for print and flood squeegee
- Single-function control for setup operation
- Single-cycle operation via foot switch and automatic cycle mode
- Extremely short setup times without the need for tools
- Pneumatic screen frame locking
- Metal vacuum base plate with micrometric fine adjustment in X and Y
direction
- Pneumatically adjustable squeegee pressure
- Adjustable squeegee angle, readable via scale
- Squeegee tilt adjustment (snowplow system)
- Pneumatically retractable registration pins
- Pneumatic ejection pin
TECHNICAL DATA
- Maximum print format: 400 x 600 mm
- Vacuum plate size: 500 x 700 mm
- Vacuum area: 405 x 600 mm
- Maximum screen frame size: 700 x 940 mm
- Screen frame profile: 25 – 47 mm
- Maximum material thickness: 0 – 200 mm
- Working height: 960 mm
- Screen lift height: 270 mm
- Adjustable print speed: 125 – 750 mm/sec
- Maximum output: 600 prints/hour
- Micrometric fine adjustment: ±10 mm
- Squeegee angle adjustment: ±9°
- Electrical connection: 400 V, 50/60 Hz
- Operating air pressure: 5 – 7 bar
DIMENSIONS & WEIGHT
- Width: 1300 mm
- Depth: 1060 mm
- Height: 1600 mm
- Weight: approx. 485 kg
