Manufacturer: Finn-Power OY, Kauhava, Finland
Model: F6 SV
Year of manufacture: 2005
Machine weight: 13500 kg
Operating hours: approximately 66,603 hours
Note: housing is not included in the purchase
Technical Data
- Punching force: 30 t (300 kN)
- Maximum workpiece size (L x W): 4061 x 1528 mm
- Maximum workpiece thickness: 8 mm
- Maximum workpiece weight: 200 kg
- Rapid traverse X axis: 80 m/min
- Rapid traverse Y axis: 60 m/min
- Number of turret stations: 20
- Turret rotation speed: 30 rpm
- Tool type: thick turret
- Maximum tool diameter: 89 mm
- Tool change time: 1 to 3 seconds
- Maximum CNC rotating tool diameter: 89 mm
- Maximum CNC rotating tool speed: 58 rpm
- Maximum travel speed: 100 m/min
- Drilling accuracy: 0.1 mm
- Positioning accuracy: 0.08 mm
- Power supply: 47 kVA
- Average power consumption: 24 kW
- Oil tank capacity: 330 l
- Maximum operating pressure: 300 bar
- Dimensions (L x W x H): 5900 x 6300 x 2500 mm
- Total machine weight: 13500 kg
- Tables: extended
- CNC control: Siemens Sinumerik 840D
- Pneumatic clamps: 3 pieces
- Turret head: 20 stations
- Multitool head: 24 stations
Some tools can be included
As mentioned, the equipment has since been dismantled and can be
loaded shortly.
