KAESER TCH 22

[ GENERAL DATA ]

* Equipment Type: Non-Cycling Refrigerated Air Dryer

* Manufacturer: Kaeser Kompressoren (Germany)

* Series: TAH - TBH - TCH Series

[ PERFORMANCE ]

* Flow Capacity: 2.20 m³/min (approx. 77.7 CFM)

* Pressure Dew Point: +3 °C (+37.4 °F)

* Pressure Loss: 0.20 bar

* Max Inlet Temp: +50 °C (+122 °F)

[ MECHANICAL & PRESSURE ]

* Max Working Pressure:16 to 18 bar (232 to 261 PSI)

* Air Connection: G 1 (Female Thread)

* Condensate Outlet: G 1/4

* Condensate Drain: ECO-DRAIN (Electronic, Zero Pressure Loss)

[ ELECTRICAL & REFRIGERATION ]

* Power Supply: 230 V / 1 Phase / 50 Hz or 60 Hz

* Power Consumption: 0.46 kW (at 100% volume)

* Refrigerant Type: R-134a

* Cooling Method: Air-Cooled Fan Assembly

[ DIMENSIONS & WEIGHT ]

* Height: 879 mm (34.6 in)

* Width: 427 mm (16.8 in)

* Depth: 608 mm (23.9 in)

* Total Weight: 55 kg (121.2 lbs)
