LVD PPEB Gebrauchtmaschinen (4)

Gebrauchte LVD PPEB 320/40.

Eckdaten: 80 t, 2000 mm

Gebrauchte LVD PPEB-EQ 80/2000. Inv. Num. : 7022 Type: PPEB-EQ 80/2000 Produzent: LVD Erzeugt: 2008 Parametern: Steuerungssystem: CADMAN CNC Druckkraft: 80 t Maximale Biegelänge: 2000 mm Hub: 200 mm Abstand zwischen den Gestellwänden: 1500 mm Maximale Hubgeschwindigkeit: 130 mm/s Maximale Biegegeschwindigkeit: 11 mm/s Maximale Rückzuggeschwindigkeit: 115 mm/s Gesamtleistungsbedarf: 12.5 kW Hauptmotorleistung: 7.5 kW

Gebrauchte LVD PPEB-8 400/6100.

Gebrauchte LVD PPEB 110/30.

Gebrauchte LVD PPEB EASY FORM 320/40.

Gebrauchte LVD PPEB EASY FORM 320/40.

Eckdaten: 500 t, 6100 mm, 4060 mm

Gebrauchte LVD PPEB Easy Form 500 / 61. Druckkraft 5000 kN Druck 290 bar Arbeitslänge 6100 mm Ständerweite 4060 mm Hub 500 mm Abstand Tisch - Stößel erhöht 770 mm Ständerausladung 400 mm Tischbreite 200 mm max. Tischbel. 2500 kN / m gr. Schliessgeschwindigkeit 100 mm/s Arbeitsgeschw 9 mm/s Rücklaufgeschwindigkeit 80 mm/s Hauptmotor 37 KW Ölinhalt 650 L Maschinengewicht ca. 69 t LVD grafische 3-D Touch-B Steuerung mit 19" Bildschirm Y1-Y2 elektronische Absenkeinstellung und Synchronisierung der Zylinder EASY-Form Laser bei W Achse Hinteranschlag CNC Achsen Y1,Y2,X,R,V, manuell Z1-Z2, X-duo Hinteranschlag: Anschlagbereich 1000mm, Verstellbereich 600mm, Wiewderholgenauigkeit 0,025mm, Versetllgeschwindigkeit 550mm/s R-Achse - Höhenverstellung des Anschlagbalkens 200 mm, Wiederholge ...

Gebrauchte LVD PPEB 135/30 Easy-Form.

Gebrauchte LVD PPEB-H.

Gebrauchte LVD EMF OH 300 SP. Druckleistung max. 300 t, Tisch 1500 x 1000 mm, Hub max. 500 mm

Gebrauchte LVD EMF OH 300 SP.

Gebrauchte LVD MV 25 - 4. Max. Schnittlaenge: 2540 mm Max. Schnittstaerke: 4 mm Stahl Moto. Hinteranschlag bis 750 mm Seitenanschlag Gewicht: 4000 kg

Gebrauchte LVD EHT DELTA 1250 RS TK. The LVD EHT DELTA 1250 RS TK turret punching machine was built in 1999. It is equipped with a MNC 32000 CNC control. The punching machine has a maximum pressure of 20 tons and allows the processing of a sheet with dimensions of 1250×1250 mm and a thickness of 4.5 / 6 mm. The machine performs a maximum of 650 beats per minute. The press is equipped with a hydraulic system, a turret with four stations (A, B, C, D) and a clearance adjustment sensor G8823142. Technical parameters: – CNC control: MNC 32000 – maximum pressing force: 20 tons – sheet dimensions X x Y: 1250 x 1250 mm – sheet thickness: 4.5 / 6 mm – maximum number of strokes: 650 1 / min – rated number of strokes: 300 1 / min – oil tank: 200 L – total power: 18.7 kW – engine: 11 kW – voltage: 400 V – weight: 17 tons Hydraulic System – Thick Turret: †...

Gebrauchte LVD PHOENIX FL-4020 10KW FIBER. 4000 x 2000mm 10000w / 10KW FIBER laser

Gebrauchte LVD PHOENIX FL-4020 6 KW FIBER. 4000 x 2000mm 6000w / 6 KW FIBER

Gebrauchte LVD TPI 80/25. Pressa marca LVD - tipo TPI 80/25 - 80 ton

Gebrauchte LVD Phoenix FL6020.

Gebrauchte LVD MVB 3100 x 6 mm. LVD MVB 3100 x 6 mm Cutting length: 3100 mm Max sheet thickness st 45: 6 mm Passage between uprights: 3300 mm Strokes/min: 18 > 60 str/min Backgauge: 750 mm Adjustable cuttingedge: 0,5 > 2,0° Electric motor (power): 7,5 kW Weight: 6 ton

Gebrauchte LVD-6020 - impuls 6020- IMPULS 6000 X 2000. CUTTING CAPACITY 4KW CUTTING PLATES 6000 X 2000 MACHINE WAS COMPLETE OWERHAULED 2 YEARS AGO - SERVIS COST WAS 35000 EUR LAST SERVICE WAS MADE 6 MONTHS AGO MACHINE RUNNING IN THE PRODUCTION TILL FIRST WEEK IN MARCH 2022 WE OFFER MACHINE LOADED ON TRUCK. NEEDS 2 TRUCK FOR TRANSPORT, NORMAL TRUCK FOR CLIENT WE CAN ORGANIZE TRANSPORT AS WELL WE OFFER MACHINE FREE LOADED ON TRUCK. LASER- GE FANUC C4000 - MODEL E TRANSPORT FOR CUSTOMER WE CAN ORGANIZE AS WELL

Gebrauchte LVD IMPULS 6020.

Gebrauchte LVD 62910013 SSI XY-AXIS RF Converter. LVD 62910013 SSI XY-AXIS RF Converter

Gebrauchte LVD HST 3100 x 6 mm. LVD HST 3100 x 6 mm Cutting length: 3100 mm Max sheet thickness st 45: 6 mm Strokes/min: 7 -> 35 str / min Adjustable cutting device: 0,05 > 0,8 Adjustable cuttingedge: 0,5 > 2,5° Electric motor (power): 9,5 kW Length: 4110 mm Depth: 1820 mm Height: 1850 mm Weight: 5,5 ton

Gebrauchte LVD MVN 25 / 4. gebr. hydr. Tafelschere, Fabr. LVD, Type MVN 25 / 4, Bj. 1984 Leistung 2500 x 4 mm mit Hinteranschlag mit Dokumentation Weiteres Zubehör: - Fördertisch - Hubtisch

Gebrauchte LVD Sirius 3015 PLUS.

Gebrauchte LVD Siena strippit 1212. LVD Siena strippit 1212 punching machine was manufactured in 2005 in Belgium by LVD Group NV. The machine, designed for precision punching of steel and aluminium sheets, is distinguished by the use of reliable components with excellent performance, which guarantee a wide range of machining options and high flexibility. Combined with a compact design based on a one-piece frame, the SIENA 20 1212 punching machine is an indispensable tool for both unit and batch production, offering easy operation and fast set-up times. The LVD STRIPPIT 1212 sheet metal punching machine features, among others, a 27-position STRIPPIT turret with 3 auto-index stations and MultiTool support. The tools punch metal sheets with a force of 20 tonnes on a large brush table, which protects the surface of the workpiece from scratches and nicks while increasing the quality of mac ...

Gebrauchte LVD DELTA 1500 LB-TK.

Gebrauchte LVD PPBLH 200/30. Angebot 25100 Technische Daten: - Druckleistung 200 t - Arbeitsbreite 3050 mm - Durchgang zwischen den Ständern 2550 mm - Tischbreite 180 mm - Ausladung 250 mm - Einbauhöhe 400 mm - Zustellgeschwindigkeit 80 mm/sek. - Arbeitsgeschwindigkeit 6,7 mm/sek. - Rückzuggeschwindigkeit 67 mm/sek. - Stößelhub 150 mm - Verstellbereich Festanschläge 120 mm - Antrieb 400 V 14,5 kW - Platzbedarf ca. B 3800 x H 2980 x T 1700 mm - Gewicht ca. 11500 kg - mit: - Hinteranschlag mit 2 Anschlagfingern - Rehfußwerkzeug - 4-fach Universalmatrize - Zweihandbedienpult, Fußtaster,

Gebrauchte LVD Electra-FL 3015.

Gebrauchte LVD HST 25/6.

Gebrauchte LVD PPBL 200 ton x 4100 mm. LVD PPBL 200 ton x 4100 mm Capacity: 200 ton x 4100 mm Backgauge: manual Passage between uprights: 3150 mm Max stroke: 150 mm Max distance between table -- ram: 400 mm Depth of throat: 250 mm Table width: 200 mm Locking speed: 100 mm/sec Working speed: 6,5 mm/sec Returning speed: 65 mm/sec Electric motor (power): 11 kW Weight: 13,4 ton

Gebrauchte LVD PPS-TS 100 ton x 3100 mm CNC. LVD PPS-TS 100 ton x 3100 mm CNC Capacity: 100 ton x 3100 mm Backgauge: CNC Control: Cadman Express Passage between uprights: 2550 mm Max stroke: 150 mm Max distance between table -- ram: 350 mm Depth of throat: 250 mm Locking speed: 100 mm/sec Working speed: 10 mm/sec Returning speed: 80 mm/sec Electric motor (power): 16 kW

Gebrauchte LVD PPBL-H 135 ton x 3100 mm. LVD PPBL-H 135 ton x 3100 mm Capacity: 135 ton x 3100 mm Passage between uprights: 2550 mm Max stroke: 130 mm Max distance between table -- ram: 310 mm Depth of throat: 200 mm Table width: 140 mm Locking speed: 100 mm/sec Working speed: 7 mm/sec Returning speed: 65 mm/sec Electric motor (power): 7,5 kW Weight: 6,5 ton

Gebrauchte LVD PPBL-H 70 ton x 3100 mm. LVD PPBL-H 70 ton x 3100 mm Capacity: 70 ton x 3100 mm Passage between uprights: 2550 mm Max stroke: 100 mm Max distance between table -- ram: 300 mm Depth of throat: 200 mm Table width: 140 mm Locking speed: 100 mm/sec Working speed: 7 mm/sec Returning speed: 60 mm/sec Electric motor (power): 4 kW Length: 3200 mm Depth: 1350 mm Height: 2100 mm Weight: 5 ton

Gebrauchte LVD PPBL 70 ton x 3100 mm. LVD PPBL 70 ton x 3100 mm Capacity: 70 ton x 3100 mm Passage between uprights: 2550 mm Max stroke: 100 mm Max distance between table -- ram: 300 mm Depth of throat: 200 mm Table width: 140 mm Locking speed: 80 mm/sec Working speed: 7 mm/sec Returning speed: 88 mm/sec Electric motor (power): 5 kW Length: 3200 mm Depth: 1260 mm Height: 2100 mm Weight: 4 ton

Gebrauchte LVD MNC 810. LVD MNC 810

Gebrauchte LVD electronics G3934857. LVD electronics G3934857

Gebrauchte LVD electronics G3934462. LVD electronics G3934462

Gebrauchte LVD electronics G3934461. LVD electronics G3934461

Gebrauchte LVD MNC 50. LVD MNC 50

Gebrauchte LVD Phoenix FL 3015.

Gebrauchte LVD Phoenix.

Gebrauchte LVD CS31/13. 3000 x 13mm with power back gauge and rear sheet supports

Gebrauchte LVD Alpha 1012 Strippit.

Gebrauchte LVD PPCB 150 ton x 4100 mm CNC. LVD PPCB 150 ton x 4100 mm CNC Capacity: 150 ton x 4100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 3150 mm Max stroke: 150 mm Max distance between table -- ram: 350 mm Depth of throat: 250 mm Table width: 180 mm Locking speed: 90 mm/sec Working speed: 7,3 mm/sec Returning speed: 56 mm/sec Electric motor (power): 7,5 kW

Gebrauchte LVD PP 70 ton x 3100 mm. LVD PP 70 ton x 3100 mm Capacity: 70 ton x 3100 mm Backgauge: no backgauge Passage between uprights: 2550 mm Max stroke: 120 mm Max distance between table -- ram: 300 mm Depth of throat: 200 mm Table width: 200 mm Locking speed: 100 mm/sec Working speed: 8,5 mm/sec Returning speed: 50 mm/sec Electric motor (power): 7,5 HP Weight: 5,6 ton

Gebrauchte LVD HST-C 31 / 6.

Gebrauchte LVD PPN 50 /25.

Gebrauchte LVD PP 80 ton x 3100 mm. LVD PP 80 ton x 3100 mm

Gebrauchte LVD Load-Assist 4020.

Gebrauchte LVD CS 31/13. 3000 x 13mm Front supports, digital back gauge & rear supports
