Very agile machine made in Japan. Even faster than Robodrill for in
tooling.
MECTRON 3-axis machining centre type MTV E 210 (year 2010)
Agile high power machine for fine tooling Made in Japan. It is faster
than Robodrill, more tools.
X/Y/Z travels 250/250/250 mmpositioning precision 0,003mm repatible
+/-0,002mmmax. feed 36m/min @ 1,0g
table size 400/300mm, spindle nose 100 - 350mm of tablemax load on
table 80kg
HSK E 25 spindle, max 30000 UminRigid Tapping 8000/min30x tool
changermax tool D30x100
SINUMERIK 840DSL controlmax. program memory 2MBabsolute position
detection COMPCAD, Slope processing, Rigid tapping, Circular
interpolation, Measuring function, Polar coordinates interpolation,
Background editing, Macro, G10, USB, backslash compensation, canned
cycleNC Options: Ethernet, 4th axis, cylindrical interpolation, tool
life management, 2nd measurement function, position monitoring
function, DNC operation
with transformer and cooler
dimensions 1070/1660/1800 mm weight 1850 Kgtotal installed power
17,6kW
