Manufacturer: Orlas
Model: Creator
Year of Manufacture: 2018
Type of Machine : 3D Printer
Condition: Lightly used
Compatible Materials: Aluminium, Steel, Stainless Steel, Titanium
Technical Specifications
- Build Volume: diameter 100 mm x 110 mm
- Reservoir Volume: diameter 110 mm x 200 mm
- Laser Type: Yb Fibre Laser, 250W cw
- Wavelength: 1070 nm
- Spot Size: 40 micron
- Process Chamber: High-end, low-oxygen environment
- Recommended Shielding Gas: Argon / Nitrogen
- Extraction System: Integrated, max. flow rate 190 m3/h
- Coating System: Rotation-guided precision recoater
- Variable Blade Options: Steel, Rubber, or Brush system
- Cartridge System for fast and safe metal powder exchange
User Interface and Software
- Controller: 12-inch Microsoft Surface Pro 3 Tablet
- Control: Tablet-based monitoring and process management
- Cloud Manufacturing Technology included
- Included Software: ORLAS SUITE CAD/CAM
- Software Features: Solid slicing, 3D structure repair, automatic
support generation, full
- print strategy control
Machine Dimensions and Power
- Machine Dimensions (L x W x H): 717 mm x 858 mm x 1794 mm
- Build Chamber Door Opening: 450 mm x 180 mm
- Power Supply: 230V / 1 Phase / 50 Hz
- Max. Current: 10 A
- Weight: 350 kg
Powder Processing Unit (Included)
- Industrial vacuum for metal dust, compressed-air operated
- Dust Class: H
- 3-stage filtration system:
- Pre-filter 1: Dust bag MC K1 - Microfibre
- Pre-filter 2: Polyester needle felt EX
- Main filter: HEPA H14, Ex-rated, diameter 230 x 65 mm
- Separation efficiency: 99.999%
- Filter area: 8,000 cm2
- Max. suction volume: 150 m3/h
- Negative pressure: max. -250 mbar
- Air consumption: 30-45 m3/h
- Tank volume: 15 litres
- Dimensions (L x W x H): 380 x 380 x 540 mm
- Weight complete with accessories: 9.5 kg
- Certifications: ATEX 95 (100a), CE EX II 2 GD c II C 50°C (T6)
- Suitable for use in zones 1, 21, 2, 22
- 2 high-quality cyclone separators for powder separation included
