Centauro R800
Holzbearbeitungsmaschinen › Holzsägen › Vertikalbandsägen
RAIMANN WEINIG ProfiRip Multi-blade rip saw Vielblattkreissägen
gebrauchtGeprüfter Anbieter
Technische Daten
· ID 143876116Holzbearbeitungsmaschinen Holzsägen Vielblattkreissägen
- Zustand
- gebraucht
- Baujahr
- 2004
- Standort
- 1010 WIEN
Identifikation
HerstellerRAIMANN WEINIG ProfiRip
ModellMulti-blade rip saw
Technik
Stückzahl1
Beschreibung
RAIMANN WEINIG ProfiRip Multi-blade rip saw Vielblattkreissägen
Raimann ProfiRip KR 310 M Bj. 2004 (new rebuild in 2021 !!) mit 2 beweglichen Flanschen
Cutting width (usable)
Track width 340 mm
Total – passage width
max 950 instead of 800 mm
Cutting height with / without pressure board
115/130 mm
Workpiece length
450 mm min
Saw blade
max. diameter 380 mm
min. diameter 250 mm
Saw blade bore
80 mm
Saw spindle diameter
65 mm
Saw spindle speed
3900 rev / min
Engine
30 kW
Laser – directional lights
2 pc.
Operating push
6 bar
Infinitely variable feed – speed
8-48 m / min. 1.5 kW
Weight
3400 kgs
Voltage
400V/50Hz
Location
stock Lugendorf
Suchbegriffe: Vielblattkreissäge, Längskreissäge, Besäumsäge, Raimann ProfiRip KR310 M.
=== ENGLISH ===
Raimann KR310 M ProfiRip multi-rip saw, year 2004, rebuilt 2021. Two movable flanges; chain width 340 mm; passage width 950 mm; cutting height 115/130 mm; minimum length 450 mm; blade diameter 250–380 mm; bore 80 mm; shaft 65 mm; 3,900 rpm; main motor 30 kW; two lasers; air 6 bar; feed 8–48 m/min with 1.5 kW drive; weight approx. 3,400 kg; 400 V/50 Hz. Location: Lugendorf, Austria. Exact configuration and condition on request.
Raimann ProfiRip KR 310 M Bj. 2004 (new rebuild in 2021 !!) mit 2 beweglichen Flanschen
Cutting width (usable)
Track width 340 mm
Total – passage width
max 950 instead of 800 mm
Cutting height with / without pressure board
115/130 mm
Workpiece length
450 mm min
Saw blade
max. diameter 380 mm
min. diameter 250 mm
Saw blade bore
80 mm
Saw spindle diameter
65 mm
Saw spindle speed
3900 rev / min
Engine
30 kW
Laser – directional lights
2 pc.
Operating push
6 bar
Infinitely variable feed – speed
8-48 m / min. 1.5 kW
Weight
3400 kgs
Voltage
400V/50Hz
Location
stock Lugendorf
Suchbegriffe: Vielblattkreissäge, Längskreissäge, Besäumsäge, Raimann ProfiRip KR310 M.
=== ENGLISH ===
Raimann KR310 M ProfiRip multi-rip saw, year 2004, rebuilt 2021. Two movable flanges; chain width 340 mm; passage width 950 mm; cutting height 115/130 mm; minimum length 450 mm; blade diameter 250–380 mm; bore 80 mm; shaft 65 mm; 3,900 rpm; main motor 30 kW; two lasers; air 6 bar; feed 8–48 m/min with 1.5 kW drive; weight approx. 3,400 kg; 400 V/50 Hz. Location: Lugendorf, Austria. Exact configuration and condition on request.
