Manufacturer: Ratti
Year of Manufacture: 2008
Model: R 325N DT
Number of spindles: 90
Number of sections: 10
Spindle type: Tangential belt drive
Max. mechanical spindle speed: 9,000 min-1
Max. technological spindle speed: 7,000 min-1
Spindle pitch: 366 mm
Whorl diameter: 52/64 mm
Twisting range: 40 to 1,869 / 32 to 1,519 tpm
Yarn count range: 167 to 560 dtex
Feed Package
- Type: Bobbin
- Max. length: 290 mm
- Max. diameter: 250 mm
- Volume (smooth yarn): 4,500 g
Winding
- Number of winding decks: 1
- Traverse gear: UDR
- Max. bobbin diameter: 250 mm
- Traverse stroke: 250 mm
- Tube diameter x length: 69 x 290 mm
- Max. mechanical winding speed: 200 m/min
- Max. technological winding speed: 170 m/min
Machine Frame Dimensions
- Number of sections: 10
- Length per section: 1,830 mm
- Total machine length: 19,000 mm
- Machine width: 860 mm
- Max. height: 1,756 mm
- Height to upper winding deck: 1,414 mm
- Machine weight: 4,140 kg
- Max. installed power: 18.5 kW
Standard Equipment
- Pneumatic lift
- Yarn break monitoring
- Centrally controlled yarn reserve
